DJI
DJI Matrice 3D Intelligent Flight Battery
The DJI Matrice 3D Series Intelligent Flight Battery is the factory flight pack for the DJI Matrice 3D (M3D) and DJI Matrice 3TD (M3TD), the dock-based variants of the Mavic 3 Enterprise series that operate from DJI Dock 2. It is a 7811 mAh, 14.76 V Li-ion 4S pack rated at 115.2 Wh that powers the airframe for up to 50 minutes of flight time per pack, with a 400 charge-cycle service life and a charging temperature range of 5 °C to 45 °C. The aircraft flies on a single battery, and packs charge automatically via DJI Dock 2 between autonomous missions, or in the dedicated Matrice 3D Series Charging Kit for off-dock use.
Single-battery flight pack for the DJI Matrice 3D and Matrice 3TD on DJI Dock 2. 115.2 Wh, ~50 minute flight time, 400 cycle service life.
Features
- Factory flight battery for the DJI Matrice 3D (M3D) and Matrice 3TD (M3TD), purpose-built for autonomous DJI Dock 2 operations
- 7811 mAh, 14.76 V, 115.2 Wh Li-ion 4S chemistry (LiNiMnCoO2 / NMC) sized for the M3D / M3TD airframe and Dock 2 charging infrastructure
- Up to 50 minutes of flight time per pack (DJI lab data, no payload, ideal conditions); typical mission planning numbers run closer to 45 minutes after wind, temperature, and payload margins
- Single-battery aircraft: one pack powers the M3D or M3TD for the full flight, with the dock handling automatic battery management between missions
- Rated for 400 charge cycles, the same cycle life as the TB30 and TB65 platforms
- Charges automatically inside DJI Dock 2 between autonomous missions, or in the dedicated DJI Matrice 3D Series Charging Kit for manual operations away from the dock
- Charging temperature range of 5 °C to 45 °C (41 °F to 113 °F), one of the widest charging windows in the DJI Enterprise lineup
Specifications
| Specification | Value |
|---|---|
| Capacity | 7811 mAh |
| Standard voltage | 14.76 V |
| Max charging voltage | 17.0 V |
| Energy | 115.2 Wh |
| Cell type | Li-ion 4S |
| Chemistry | LiNiMnCoO2 (NMC) |
| Weight | Approximately 544 g per pack |
| Charging temperature | 5 °C to 45 °C (41 °F to 113 °F) |
| Rated cycle count | 400 |
| Flight time | Up to approximately 50 minutes per pack |
| Compatible aircraft | DJI Matrice 3D (M3D), DJI Matrice 3TD (M3TD) |
| Compatible charging | DJI Dock 2 (automatic); DJI Matrice 3D Series Charging Kit (manual, sold separately) |
Who this is for
- Operators running DJI Dock 2 deployments with the Matrice 3D or Matrice 3TD who need a spare or replacement flight battery for the docked aircraft
- Fleet operators standing up multiple Dock 2 sites and building per-site spare-battery inventory
- Public-safety, utility, energy, and inspection programs that operate the M3D / M3TD autonomously over routes the aircraft flies repeatedly, where a fresh battery is needed off-dock for an additional mission
- Operators with the DJI Matrice 3D Series Charging Kit who need an additional battery for manual charging away from Dock 2
What's included
- 1 × DJI Matrice 3D Series Intelligent Flight Battery
Please note: This is the flight battery for the DJI Matrice 3D (M3D) and Matrice 3TD (M3TD), the dock-based variants of the Mavic 3 Enterprise series. It is not the same battery as the DJI Mavic 3 Enterprise Series Battery (BWX260, 5000 mAh, 77 Wh) used in the standard M3E and M3T, and it is not interchangeable with that platform. Verify your aircraft variant before ordering. The aircraft, DJI Dock 2, and the Matrice 3D Series Charging Kit are sold separately.
The M3D / M3TD is a single-battery aircraft, so a single pack powers the airframe for one full flight. Plan inventory accordingly: one pack flying, one or more rotating through dock or kit-based charging.
Travel and shipping: At 115.2 Wh, the Matrice 3D battery sits in the 100 to 160 Wh range that the FAA, IATA, and most major airlines treat as a special-handling category. Spare lithium batteries in this range are typically allowed in carry-on with prior airline approval, limited to two spare packs per passenger. They are not permitted in checked baggage. Confirm your specific airline's policy before traveling, carry packs with terminals protected against short-circuit, and bring DJI's documentation in case ground staff ask for it.
FAQ
Which aircraft does this battery fit?
The DJI Matrice 3D (M3D) and the DJI Matrice 3TD (M3TD). These are the dock-based Mavic 3 Enterprise variants designed to operate from DJI Dock 2. The battery is not compatible with the standard Mavic 3 Enterprise (M3E), Mavic 3 Thermal (M3T), Mavic 3 Multispectral (M3M), consumer Mavic 3 / Mavic 3 Cine, or any other DJI airframe.
How is this different from the standard Mavic 3 Enterprise battery?
Different battery entirely. The standard M3E / M3T uses the BWX260-5000-15.4 battery: 5000 mAh, 15.4 V, 77 Wh, paired with the 100 W charging hub for manual operations. The Matrice 3D / 3TD uses this higher-capacity 7811 mAh, 14.76 V, 115.2 Wh battery built for dock-based autonomous missions, with charging handled automatically by DJI Dock 2. The two batteries are physically and electrically different and not interchangeable.
Does the aircraft fly on one battery or two?
One. The Matrice 3D and Matrice 3TD are single-battery aircraft. A single pack powers the airframe for the full flight; there is no paired-battery configuration as on the Matrice 30, Matrice 350 RTK, or Matrice 400 Series.
How long does it fly?
Up to approximately 50 minutes per pack on the Matrice 3D or Matrice 3TD, per DJI's published lab data with no payload in ideal conditions. Mission planning numbers run closer to 45 minutes after typical wind, temperature, and payload margins. Real-world flight time is shorter and varies with weather and flight profile.
How does it charge?
Two ways. During autonomous Dock 2 operations, the dock charges the battery automatically between missions; no operator action is required. For manual or off-dock charging, use the dedicated DJI Matrice 3D Series Charging Kit (sold separately). The charging temperature range is 5 °C to 45 °C (41 °F to 113 °F).
How long does the battery last?
DJI rates the Matrice 3D battery at 400 charge cycles under normal use. Service life also depends on how the pack is stored and the temperatures it's charged at. For dock-based operations, Dock 2 handles temperature-aware charging automatically; for manual operations, charge within the recommended temperature window and avoid extended storage at full charge.
Can I take it on a commercial flight?
At 115.2 Wh, the Matrice 3D battery sits in the 100 to 160 Wh range that the FAA, IATA, and most major airlines treat as a special-handling category. Spare lithium batteries in this range are typically allowed in carry-on with prior airline approval, limited to two spare packs per passenger. They are not permitted in checked baggage. Confirm your specific airline's policy before you travel, carry packs with terminals protected against short-circuit, and bring DJI's documentation in case ground staff ask for it.
How should I store the battery between missions?
If the battery is in Dock 2, the dock manages storage state automatically. For batteries kept off-dock, follow standard DJI Intelligent Battery practice: store at room temperature out of direct sunlight, and discharge to approximately 40 to 65% for storage longer than 10 days. The Intelligent Battery firmware self-discharges a stored pack toward a safe storage level over time; refer to the Matrice 3D / 3TD user manual for the recommended interval.
